RHD20AL ,RHD45A Slide Blocks

Name: RHD20AL ,RHD45A Slide Blocks
Brand: RHD20AL ,RHD45A Slide Blocks
SKU: RHD20AL ,RHD45A
Price: 1.00 USD
Availability: InStock
Rating: 4.7 (189 reviews)

Model Number	RHD20AL ,RHD45A
Minimum Order Quantity	1
Price	FOB
Packaging Details	Carton Box
Delivery Time	within one day
Payment Terms	T/T In advance
Supply Ability	5000PCS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details

Leave a Message

Product Description

Specifications

Part NO	size of combination				slide housing size							slide rail size
	H	W	W2	E	L	BÃ—J	MQÃ—l*/	L1	oil hole	T1	N	W1	H1	F	dÃ—DÃ—h
RHD15A	24	47	16	4.6	66	38Ã—30	M5Ã—8	40	Ð¤3	4.3	5	15	14	60	4.5Ã—7.5Ã—5.3
RHD20A	30	63	21.5	5	77.8	53Ã—40	M6Ã—9	48.8	M6Ã—1	5	6.5	20	18	60	6Ã—9.5Ã—8.5
RHD20AL					92.4			63.4
RHD25A	36	70	23.5	7	88	57Ã—45	M8Ã—12	57	M6Ã—1	5	6.5	23	22	60	7Ã—11Ã—9
RHD25AL					110.1			79.1
RHD30A	42	90	31	9	109	72Ã—52	M10Ã—12	72	M6Ã—1	7	6.5	28	26	80	9Ã—14Ã—12
RHD30AL					131.3			94.3
RHD35A	48	100	33	9.5	109	82Ã—62	M10Ã—13	80	M6Ã—1	8	6.5	34	29	80	9Ã—14Ã—12
RHD35AL					134.8			105.8
RHD45A	60 (62)	120	37.5	14	138.2	100Ã—80	M12Ã—15	105	M8Ã—1	10	13	45	38	105 (100)	14Ã—20Ã—17
RHD45AL					163			129.8
RHD55A	70	140	43.5	15	170	116Ã—95	M14Ã—20	121	M8Ã—1	11	13	53	44	120	16Ã—23Ã—20
RHD55AL					205.1			156.1

Part NO	Reference ï¼ˆmmï¼‰		Basic Loading(kgf)		Allow the first moment (kgfxm)			weight
Part NO	Lmax	G	Dynamicï¼ˆcï¼‰	staticï¼ˆcoï¼‰	Mx	My	Mz	slide Blockskg	slide railkgf/m
RHD15A	4000	30	850	1650	10	8	8	0.19	1.4
RHD20A	4000	30	1450	2560	22	18	18	0.4	2.6
RHD20AL	4000	30	1900	3330	28.6	23.4	23.4	0.52	2.6
RHD25A	4000	30	2140	4000	36	32	31	0.57	3.6
RHD25AL	4000	30	2996	5600	50.4	44.8	43.4	0.72	3.6
RHD30A	4000	40	2980	5490	60	50	49	1.1	5.2
RHD30AL	4000	40	3900	7190	78.5	65	65	1.4	5.2
RHD35A	4000	40	3960	7010	96	75	73	1.6	Tags: lm8uu ball bushing linear rail Recommended Products IKO Original Slide Block LRWH25 C1 T1HS ,LRWH25 IKO Industrial Linear Bearing SDE16 Original Linear Bearing LBHT 30 A-2LS , LBHT30 A-2LS Original HIR Slide Block + Linear Guide HNR30LC2UUC0+920LH Original THK Slide Block + Linear Guide SNS30LR 2 UU CO+1000LH , SNS30LR 2UU CO+1000LH IKO Original Japan Slide Block LRWH25C1HS2 IKO Original Japan Slide Block LRWH25C1HS2 IKO BK4615A Linear Bearing Shanghai Yiqiang Industrial Co.,Ltd About Company Profile Factory Tour Quality Control Contact Us News Cases Sitemap Privacy Policy Products Cylindrical Roller Bearing Needle Roller Bearing Spherical Roller Bearing All Categories China linear slide rail Supplier. Copyright © 2017 - 2023 kaylayq-bearing.com. All Rights Reserved. Developed by ECER kaylayq88@foxmail.com +8615026931462 15026931462 kayla-guo 86-15026931462 0086-21-60543247
