xProduct Details
Product Description
KOYO bearing and adapter sleeve features:
KOYO spherical roller bearings feature a large load rating and self-aligning capability. Bearing 22236RHK is suitable for low or medium speed applications which involve heavy or impact loading.
|
|
d1H |
D |
B |
|
adapter sleeve |
mm |
mm |
mm |
|
22205 RHK + H305 |
20 |
52 |
18 |
|
22206 RHK + H306 |
25 |
62 |
20 |
|
22207 RHK + H307 |
30 |
72 |
23 |
|
22208 RHK + H308 |
35 |
80 |
23 |
|
22209 RHK + H309 |
40 |
85 |
23 |
|
22210 RHK + H310 |
45 |
90 |
23 |
|
22211 RHK + H311 |
50 |
100 |
25 |
|
22212 RHK + H312 |
55 |
110 |
28 |
|
22213 RHK + H313 |
60 |
120 |
31 |
|
22214 RHK + H314 |
60 |
125 |
31 |
|
22215 RHK + H315 |
65 |
130 |
31 |
|
22216 RHK + H316 |
70 |
140 |
33 |
|
22217 RHK + H317 |
75 |
150 |
36 |
|
22218 RHK + H318 |
80 |
160 |
40 |
|
22219 RHK + H319 |
85 |
170 |
43 |
|
22220 RHK + H320 |
90 |
180 |
46 |
|
22222 RHK + H322 |
100 |
200 |
53 |
|
22224 RHK + H3124 |
110 |
215 |
58 |
|
22226 RHK + H3126 |
115 |
230 |
64 |
|
22228 RHK + H3128 |
125 |
250 |
68 |
|
22230 RHK + H3130 |
135 |
270 |
73 |
|
22232 RHK + H3132 |
140 |
290 |
80 |
|
22234 RHK + H3134 |
150 |
310 |
86 |
|
22236 RHK + H3136 |
160 |
320 |
86 |
For these KOYO 22200 series bearings, each bearing can be produced with a cylindrical bore or tapered bore. KOYO Bearings with a tapered bore can be fit and removed easily using an adapter assembly or withdrawal sleeve. Welcome to contact us for enquiry.
