Sprag Type One Way Clutch Bearing CSK12 2RS ,CSK12 P-2RS

Model Number CSK12 2RS ,CSK12 P-2RS
Minimum Order Quantity 1PCS
Price FOB
Packaging Details Carton Box
Delivery Time within one day
Payment Terms T/T In advance
Supply Ability 5000PCS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

Specifications





One Way Clutch Bearing CSK25 2RS



 CSK series one way (direction) bearing consists of a standard ball bearing, in-built special snap block and cage, widely used in mining machinery, washing machine, hydraulic machinery, printing machines, textile machinery, conveyor systems.



Type CSK is a sprag type freewheel integrated into a 62 series ball bearing (except sizes 8 and 40). It is bearing supported, delivered grease lubricated and protected against dust of more than 0,3 mm. The use of additional “nylos” type seals is recommended especially when the working temperature exceeds 50°C. Oil bath lubrication is also possible.
All the CSK versions are equipped with “formchromed” sprags. This process increases several times the overrunning life time. Torque transmission is ensured by a press fit assembly into a rigid outer housing with N6 tolerance, and onto a shaft with n6 tolerance. The initial bearing radial clearance is set at C5, and is reduced if using the press fit as specified.



Please contact us when either the ambient or the operating temperature is not within the range +5°C to +60°C. CSK..2RS is 5 mm wider but is equiped with lip seals to be water splash resistant.







Types CSK..P and CSK..PP are sprag type freewheels integrated into 62.. series ball bearings (except size 40). They are bearing supported, delivered grease lubricated and protected against dust of more than 0,3 mm.
The use of additional “nylos” type seals is recommended especially when the working temperature exceeds 50°C. Oil bath lubrication is also possible.
In addition to the basic CSK model, type CSK..P features a keyway on the inner race. For this reason it can be keyed to a shaft to k6 tolerance. The outer race must still be pressed into a rigid housing to N6 tolerance.
CSK..PP features a keyway on both the inner and outer race. The recommended mounting tolerances are h6 on the shaft and H6 in a rigid housing. Please contact us when either the ambient or the operating temperature is not within the range +5°C to +60°C.







Designation Bearing Series   Dimensions Mass Load Rating Torque Rating  Limiting Speed
d (mm) D (mm) L (mm) b (mm) t (mm) (kg) Dynamic (kN) Static (kN) (N·m) (RPM)
  CSK8        8 22 9  –    –   0.015 3.28 0.86 5 15000
  CSK12   CSK12 P   6201 12 32 10  –    –   0.04 6.1 2.77 18.6 10000
  CSK15   CSK15 P CSK15 PP 6202 15 35 11  –    –   0.06 7.4 3.42 34 8400
  CSK17  CSK17 P CSK17 PP 6203 17 40 12  –    –   0.07 7.9 3.8 60 7350
  CSK20 CSK20 P CSK20 PP 6204 20 47 14  –    –   0.11 9.4 4.46 100 6000
  CSK25   CSK25 P CSK25 PP 6205 25 52 15  –    –   0.14 10.7 5.46 170 5200
  CSK30   CSK30 P CSK30 PP 6206 30 62 16  –    –   0.21 11.7 6.45 276 4200
  CSK35   CSK35 P CSK35 PP 6207 35 72 17  –    –   0.3 12.6 7.28 350 3600
  CSK40  CSK40 P CSK40 PP  –   40 80 22  –    –   0.5 15.54 12.25 650 3000
  CSK8 2RS        –   8 22 9  –    –   0.015 3.28 0.86 5 15000
CSK12 2RS   CSK12 P-2RS    –   12 32 14  –    –   0.05 6.1 2.77 18.6 10000
CSK15 2RS   CSK15 P-2RS    –   15 35 16  –    –   0.07 7.4 3.42 34 8400
CSK17 2RS   CSK17 P-2RS    –   17 40 17  –    –   0.09 7.9 3.8 60 7350
  CSK20 2RS CSK20 P-2RS    –   20 47 19  –    –   0.145 9.4 4.46 100 6000
CSK25 2RS   CSK25 P-2RS    –   25 52 20  –    –   0.175 10.7 5.46 170 5200
  CSK30 2RS CSK30 P-2RS    –   30 62 21  –    –   0.27 11.7 6.45 276 4200
CSK35 2RS   CSK35 P-2RS    –   35 72 22  –    –   0.4 12.6 7.28 350 3600
  CSK40 2RS  CSK40 P-2RS    –   40 80 27  –    –   0.6 15.54 12.25
