THK Linear slide blocks

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

Specifications





Bearing:Linear slide block bearing

As a professional linear motion products manufacturer with many years expriences,we could offer many kinds of linear motion ball slide block bearings with

 good quality but more competitive price in this field.



1.Complete sliding units system with high accurrfangce and can be moved without deflection

2.Long life use.

3..Prompt delivery and good service.

4.Stocking feet and low batch wholesale.

5.ISO9001:2000.



Model sizes and tenique data sheet for your reference:

sklslide block bearings

Model No. Outer dimensions Basic  load rating
Height Width Lenght Radial  Reverse radial Side
H W Dynamic
rating
C
Static
rating
C0
Dynamic
rating
CL
Static
rating
C0L
Dynamic
rating
CT
Static
rating
C0T
  mm mm mm kN kN kN kN kN kN
HSR 15R(Ct) 28 34 56.6 8.33 13.5 8.33 13.5 8.33 13.5
HSR 20R(Ct) 30 44 74 13.8 23.8 13.8 23.8 13.8 23.8
HSR 25R(Ct) 40 48 83.1 19.9 34.4 19.9 34.4 19.9 34.4
HSR 30R(Ct) 45 60 98 28 46.8 28 46.8 28 46.8
HSR 35R(Ct) 55 70 109.4 37.3 61.1 37.3 61.1 37.3 61.1



slide block bearings feature:

1.low cost

2.linear motion system

3.small load

4.high-precision smooth movement

5.HS code:8483 3000







Looking forward to your inquiry.
