THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA

  • THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA
Model Number HSR 35M1B,HSR 35M1LA,HSR 25M1LA
Minimum Order Quantity 1
Price FOB
Packaging Details Carton Box
Delivery Time within one day
Payment Terms T/T In advance
Supply Ability 5000PCS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

Specifications








Return
SR-M1W















Dimensional drawing


Model No. Outer dimensions Basic load rating Detail specifications CAD Dimensional drawing
Radial 2D (DXF) 3D
Height
M		 Width
W		 Length
L		 Dynamic
rating
C		 Static
rating
C0
mm mm mm kN kN
SR 15M1W 24 34 57 9.51 19.3 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1 — THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 2
SR 20M1TB 28 59 66.2 12.5 25.2 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
SR 25M1TB 33 73 83 20.3 39.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
SR 30M1TB 42 90 96.8 30 56.8 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
SR 35M1TB 48 100 111 41.7 77.2 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
SR 15M1V 24 34 40.4 5.39 11.1 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1 — THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 2
SR 20M1SB 28 59 47.3 7.16 14.4 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
SR 25M1SB 33 73 59.2 11.7 22.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
SR 30M1SB 42 90 67.9 17.2 32.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
SR 35M1SB 48 100 77.6 23.8 44.1 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 15M1A 24 47 59.6 8.33 13.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1 — THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 2
HSR 25M1LA 36 70 103 27.2 45.9 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 30M1LA 42 90 121.4 37.3 62.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 35M1LA 48 100 137.4 50.2 81.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 15M1B 24 47 59.6 8.33 13.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1 — THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 2
HSR 25M1LB 36 70 103 27.2 45.9 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 30M1LB 42 90 121.4 37.3 62.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 35M1LB 48 100 137.4 50.2 81.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 15M1R 28 34 59.6 8.33 13.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1 — THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 2
HSR 25M1LR 40 48 103 27.2 45.9 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 30M1LR 45 60 121.4 37.3 62.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 35M1LR 55 70 137.4 50.2 81.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
HSR 15M1YR 28 33.5 59.6 8.33 13.5 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1 — THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 2
RSR 12M1N 13 27 47.7 4.3 6.65 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
RSR 15M1N 16 32 61 7.16 10.7 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
RSR 20M1N 25 46 86.3 14.2 20.6 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 0 THK Linear Guide and Slide Block HSR 35M1B,HSR 35M1LA,HSR 25M1LA 1
RSR 9M1K 10 20 30.8 Tags:
