NTN Single row cylindrical roller bearings NU322G1C4
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
Product Description
Technical data NU322G1C4
| Product definition | |
|---|---|
| d | 110 mm |
| D | 240 mm |
| B | 50 mm |
| E | 207 mm |
| F | 143 mm |
| rs min | 3 mm |
| r1s min | 3 mm |
| Radial clearance class | C4 |
| Mass (without HJ ring) | 11 kg |
| Brand | NTN |
| Product performance | |
|---|---|
| Dynamic load, C | 36,000 daN |
| Static load, C0 | 40,000 daN |
| Fatigue limit load, Cu | 4,120 daN |
| Nlim (oil) | 3,500 rpm |
| Nlim (grease) | 3,000 rpm |
| Min operating temperature, Tmin | -40 °C |
| Max operating temperature, Tmax | 120 °C |
| Abutment dimensions | |
|---|---|
| da min | 123 mm |
| da max | 140 mm |
| db min | 145 mm |
| Da max | 227 mm |
| ra max | 2.5 mm |
| r1a max | 2.5 mm |
Type Type NTN Part NO Description
H E NU322ET2 Large Cylindrical Roller Bearing
H E NU322ET2C3 Large Cylindrical Roller Bearing
H E NU322G1 Large Cylindrical Roller Bearing
H E NU322G1C3 Large Cylindrical Roller Bearing
H E NU322G1C3P6 Large Cylindrical Roller Bearing
H E NU322G1C4 Large Cylindrical Roller Bearing
H E NU322G1C4P6 Large Cylindrical Roller Bearing
H E NU322G1CM Large Cylindrical Roller Bearing
H E NU322G1P5 Large Cylindrical Roller Bearing
H E NU322G1P6 Large Cylindrical Roller Bearing
H E NU322SMG1 Large Cylindrical Roller Bearing
H E NU324 Large Cylindrical Roller Bearing
H E NU324C3 Large Cylindrical Roller Bearing
H E NU324EG1 Large Cylindrical Roller Bearing
H E NU324EG1C3 Large Cylindrical Roller Bearing
H E NU324G1 Large Cylindrical Roller Bearing
H E NU324G1C3 Large Cylindrical Roller Bearing
H E NU324G1CM Large Cylindrical Roller Bearing
H E NU324G1CMU41 Large Cylindrical Roller Bearing
H E NU324G1PX7 Large Cylindrical Roller BEARING
