NSK deep groove ball bearing 6309ZZ , 6308ZZ , 6210ZZ

Place of Origin Japan
Brand Name NSK
Model Number 6309ZZ , 6308ZZ , 6210ZZ
Minimum Order Quantity 1PCS
Price FOB
Packaging Details Carton Box
Delivery Time within one day
Payment Terms T/T In advance
Supply Ability 5000PCS

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Leave a Message
Product Description

Deep groove ball bearing relative series

6000 Series
N0. Bore O.D Width Chamfer Load Rating   Maximuum Seed   Weight
  mm mm mm mm Dynamic Static Grease Oil Kg/pcs
          Cr Cor r/min r/min
604 4 12 4 0.2 0.97 0.36 36000 44000 0.0021
605 5 14 5 0.2 1.33 0.505 32000 40000 0.0035
606 6 17 6 0.3 2.19 0.865 30000 38000 0.006
607 7 19 6 0.3 2.24 0.91 28000 36000 0.008
608 8 22 7 0.3 3.35 1.4 26000 34000 0.012
609 9 24 7 0.3 3.4 1.45 24000 32000 0.014
6000 10 26 8 0.3 4.55 1.96 22000 30000 0.019
6001 12 28 8 0.3 5.1 2.39 19000 26000 0.021
6002 15 32 9 0.3 5.6 2.83 18000 24000 0.03
6003 17 35 10 0.3 6.8 3.35 17000 22000 0.039
6004 20 42 12 0.6 9.4 5.05 15000 19000 0.069
6005 25 47 12 0.6 10.1 5.85 14000 18000 0.08
6006 30 55 13 0.6 13.2 8.3 12000 15000 0.116
6007 35 62 14 1 16 10.3 10000 14000 0.115
6008 40 68 15 1 16.8 11.5 8000 11000 0.19



6200 Series
N0. Bore O.D Width Chamfer Load Rating   Maximuum Seed   Weight
  mm mm mm mm Dynamic Static Grease Oil Kg/pcs
          Cr Cor r/min r/min
624 4 13 5 0.2 1.15 0.4 36000 45000 0.0032
625 5 16 5 0.3 1.76 0.68 32000 40000 0.0050
626 6 19 6 0.3 2.34 0.885 28000 36000 0.0080
627 7 22 7 0.3 3.35 1.400 26000 34000 0.0130
628 8 24 8 0.3 4.00 1.590 24000 32000 0.0170
629 9 26 8 0.3 4.55 1.960 22000 30000 0.0190
6200 10 30 9 0.6 5.10 2.390 19000 26000 0.0300
6201 12 32 10 0.6 6.10 2.750 18000 24000 0.0360
6202 15 35 11 0.6 7.75 3.600 17000 22000 0.0460
6203 17 40 12 0.6 9.60 4.600 16000 20000 0.0650
6204 20 47 14 1 12.80 6.650 14000 18000 0.1070
6205 25 52 15 1 14.00 7.850 12000 16000 0.1250
6206 30 62 16 1 19.50 11.300 10000 13000 0.2010



6300 Series
N0. Bore O.D Width Chamfer Load Rating   Maximuum Seed   Weight
  mm mm mm mm Dynamic Static Grease Oil Kg/pcs
          Cr Cor r/min r/min
6300 10 35 11 0.6 8.2 3.5 18000 24000 0.053
6301 12 37 12 1 9.7 4.2 17000 22000 0.06
6302 15 42 13 1 11.4 5.45 16000 20000 0.082
6303 17 47 14 1.0 13.5 6.55 15000 19000 0.115
6304 20 52 15 1.1 15.9 7.9 14000 17000 0.144



6800 Series
N0. Bore O.D Width Chamfer Load Rating   Maximuum Seed   Weight
  mm mm mm mm Dynamic Static Grease Oil Kg/pcs
          Cr Cor r/min r/min
685 5 11 3 0.15 0.715 0.282 35000 45000 0.0011
686 6 13 3.5 0.15 1.08 0.44 33000 42000 0.0019
687 7 14 3.5 0.15 1.17 0.505 31000 40000 0.0021
688 8 16 4 0.2 1.61 0.715 29000 38000 0.0031
689 9 17 4 0.2 1.72 0.82 28000 36000 0.0032
6800 10 19 5 0.3 1.83 0.925 26000 34000 0.005
6801 12 21 5 0.3 1.92 1.04 22000 30000 0.006
6802 15 24 5 0.3 2.08 1.26 20000 28000 0.007
6803 17 26 5 0.3 2.23 1.46 19000 26000 0.008
6804 20 32 7 0.3 4 2.47 17000 22000 0.019
6805 25 37 7 0.3 4.3 2.95 15000 19000 0.022
6806 30 42 7 0.3 4.7 3.65 13000 17000 0.026
6807 35 47 7 0.3 4.9 4.05 11000 15000 0.029



6900 Series
N0. Bore O.D Width Chamfer Load Rating   Maximuum Seed   Weight
  mm mm mm mm Dynamic Static Grease Oil Kg/pcs
          Cr Cor r/min r/min
693 3 8 3 0.15 0.56 0.18 44000 52000 0.0006
694 4 11 4 0.15 0.715 0.276 38000 47000 0.0018
695 5 13 4 0.2 1.08 0.43 34000 43000 0.0024
696 6 15 5 0.2 1.35 0.53 32000 40000 0.0038
697 7 17 5 0.3 1.61 0.715 30000 38000 0.0052
698 8 19 6 0.3 1.99 0.865 28000 36000 0.0073
690 9 20 6 0.3 2.48 1.09 27000 34000 0.0082
6900 10 22 6 0.3 2.7 1.27 25000 32000 0.009
6901 12 24 6 0.3 2.89 1.46 20000 28000 0.011
6902 15 28 7 0.3 3.65 2 19000 26000 0.016
6903 17 30 7 0.3 4.65 2.58 18000 24000 0.018
6904 20 37 9 0.3 6.4 3.7 17000 22000 0.036
6905 25 42 9 0.3 7.05 4.55 14000 18000 0.042
6906 30 47 9 0.3 7.25 5 12000 16000 0.048
6907 35 55 10 0.3 9.55 6.85 10000 14000 0.074
